STAINLESS STEEL 304 SHORT BUTT HINGE 151MMX65MM Brass grease nipple

Stainless Steel 304 Short Butt Hinge
Overall Length: 151 mm
Width: 65 mm
Design: Butt hinge with tapered top leaf
Material: Stainless Steel 304 selected for its excellent corrosion resistance, durability, and suitability for demanding environments.

Lubrication Feature:
Fitted with a brass grease nipple to allow easy, periodic lubrication. This reduces friction, minimises wear, and enhances long-term performance particularly important for outdoor or heavy duty applications where hinges are exposed to weather or frequent movement.

Load Ratings:

• Axial Load: 3000 N (≈ 300 kg)

• Radial Load: 3200 N (≈ 320 kg)

The above figures are guides only. IRS accepts no responsibility for the installation of the hinges or the fixings used.
